Codigo: MS-12TE
Descripción
Sensor PIR exterior TAKEX MS-12TE 90° un cabezal móvil - 2 zonas de detección, función pared.
Description
Dual-Zone system reduces false alarms for reliable outdoor detection.
Dual-Zone: Up to 12m (40ft) x 90 degrees
Features:
- Dual-Zone sensor head can resist detection of small animals
- Advanced Variable Multi-area Detection System
- Selectable NO/NC relay output with Timer Function
- Day/Night Sensing
- Adjustable Pulse Count & Sensitivity
- 0.8-1.2m Mounting Height
Specifications:
Detection system
Passive Infrared
Coverage
When horizontal detection
Angle: 90°
Detection distance : 40ft (12m)
Horizontal zone : 7 zones
Downward zone: 7 zones
Coverage adjustment
Horizontal : +/-90°
Detection distance : 10′ to 40′ (3 to 12m)
(By adjusting vertical angle of a downward zone)
Supply voltage
12 to 30V DC (non-polarity)
Current consumption
35mA MAX.
Alarm output
Dry contact relay output N.C./N.O. selectable
Contact capacity : 30V (AC・DC), 0.5A MAX. (Resistive load)
Contact operation : Detection time + off delay
(2sec. -5min. approx.)
Detection settings
Daylight: Night (10 lux) – Day and Night
Tamper output
Dry contact relay output N/C
Contact capacity : 30V (AC/DC), 0.5A MAX. (Resistive load)
Operation LED
Red LED
Blinking at warming up (LED disabled)
Lighting at alarm (LED disabled)
Pulse count settings
once / three times (with a switch)
Sensitivity adjustment
Approx. 30% (L) – Approx. 170% (H) (By potentiometer)
Connection
Terminals
Ambient temperature
-4F to +122F (-20C to +50C)
Mounting position
Indoor / Outdoor
Weight
13.7oz (390g)
Appearance
Body: AES resin
Lens: PE resin
Accessories
Tapping screw: 2
Area masking sheet: 1
