Descripción

• High quality imaging with 2 MP resolution
• Water and dust resistant (IP67)
• Easy installation with Power over Ethernet (PoE) technology

• Cámara
• Sensor de imagen1/2.9"" Progressive Scan CMOS
• Max. Resolución1920 × 1080
• Iluminación mínimaColor: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR
• Tiempo de obturación1/3 s to 1/100,000 s
• Día y NocheIR cut filter
• Ajuste de ánguloPan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

• Lente
• LenteFixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV

  2.8 mm, horizontal FOV 94°, vertical FOV 51°, diagonal FOV 112°

  4 mm, horizontal FOV 80°, vertical FOV 44°, diagonal FOV 94°

• Montura del lenteM12
• Iris TypeFixed
• AperturaF2.2

• DORI
• DORI

  2.8 mm, D: 48 m, O: 19 m, R: 9 m, I: 4 m

  4 mm, D: 55 m, O: 22 m, R: 11 m, I: 5 m

• Iluminador
• Tipo de luz suplementariaIR
• Rango de luz suplementariaUp to 20 m
• Luz de suplemento inteligenteYes
• IR Wavelength850 nm

• Vídeo
• Main stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 720)

  60 Hz: 30 fps (1920 × 1080, 1280 × 720)

• Sub-stream

  50 Hz: 25 fps (640 × 480, 640 × 360)

  60 Hz: 30 fps (640 × 480, 640 × 360)

• Compresión de video

  Main stream: H.265+/H.265/H.264+/H.264,

  Sub-stream: H.265/H.264

• Vídeo bitrate32 Kbps to 8 Mbps
• Tipo H.264Baseline Profile,Main Profile,High Profile
• Tipo H.265Main Profile
• Bit Rate ControlCBR,VBR

• Red
• SeguridadPassword protection, complicated password, watermark, basic and digest authentication for HTTP, security audit log, host authentication (MAC address)
• Vista en vivo simultáneaUp to 6 channels
• APIISAPI,SDK
• ProtocolosTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, UDP, QoS
• Usuario/operador

  Up to 32 users

  3 user levels: administrator, operator, and user

• ClienteiVMS-4200
• Navegador web

  Plug-in required live view: IE 10, IE 11,

  Local service: Chrome 57.0+, Firefox 52.0+

• Imagen
• Wide Dynamic Range (WDR)Digital WDR
• SNR≥ 52 dB
• Interruptor día/nocheDay,Night,Auto,Schedule
• Mejora de la imagenBLC,HLC,3D DNR
• Configuración de imagenSaturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser

• Interfaz
• Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port

• Evento
• Evento BásicoMotion detection, exception
• LinkageNotify surveillance center

• General
• alimentación

  12 VDC ± 25%, 0.41 A, max. 5 W,Ø5.5 mm coaxial power plug,reverse polarity protection,

  PoE: IEEE 802.3af, Class 3, max. 6.5 W

• MaterialPlastic
• Dimensión138.8 mm × 60.9 mm × 57.9 mm (5.5"" × 2.4"" × 2.3"")
• Dimensión del paquete163 mm × 75 mm × 75 mm (6.4"" × 3.0"" × 3.0"")
• Approx. 175 g (0.4 lb.)
• Con peso del paqueteApprox. 250 g (1.1 lb.)
• Condiciones de almacenaje-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Condiciones de inicio y funcionamiento-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• IdiomaEnglish, Ukrainian
• Función generalHeartbeat,anti-banding,mirror,password protection,password reset via email

• Certificaciones
• EMC

  CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014

• Seguridad

  CB: IEC 62368-1: 2014+A11,

  CE-LVD: EN 62368-1: 2014/A11: 2017

• Ambiente

  CE-RoHS: 2011/65/EU,

  WEEE: 2012/19/EU,

  Reach: Regulation (EC) No 1907/2006
