Descripción

4MP Wi-Fi 6 Outdoor Bullet Camera

Support Wi-Fi 6

Support Human and Vehicle Detection

Built-in microphone and speaker, support two-way audio

Good night-time performance with up to 30 m IR and 30 m white light

Water and dust resistant (IP66)

Cámara

Sensor de imagen

1/2.7" Progressive Scan CMOS

Max. Resolución

2560 × 1440

Iluminación mínima

Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux @ (F1.6, AGC ON)

Tiempo de obturación

1/3 s to 1/100,000 s

Día y Noche

IR cut filter

Ajuste de ángulo

Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

Lente

Lente

Fixed focal lens, 2.8 and 4 mm optional

Focal Length & FOV

2.8 mm, horizontal FOV 124°, vertical FOV 70°, diagonal FOV 142°

4 mm, horizontal FOV 91°, vertical FOV 49°, diagonal FOV 108°

Montura del lente

M12

Iris Type

Fixed

Apertura

F1.6

Depth of Field

2.8 mm: 1.2 m to ∞

4 mm: 1.3 m to ∞

DORI

DORI

2.8 mm, D: 55 m, O: 21 m, R: 11 m, I: 5 m

4 mm, D: 67 m, O: 26 m, R: 13 m, I: 6 m

Iluminador

Tipo de luz suplementaria

IR,White Light

Rango de luz suplementaria

IR: up to 30 m

White Light: up to 30 m

Luz de suplemento inteligente

Yes

IR Wavelength

850 nm

Vídeo

Main stream

50 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

60 Hz: 20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

Sub-stream

50 Hz: 20 fps (768 × 432)

60 Hz: 20 fps (768 × 432)

Compresión de video

Main stream: H.265/H.264,

Sub-stream: H.265/H.264

Vídeo bitrate

32 Kbps to 4 Mbps

Tipo H.264

Baseline Profile,Main Profile,High Profile

Tipo H.265

Main Profile

Bit Rate Control

CBR,VBR

Región de interés (ROI)

1 fixed region for main stream

Audio

Tipo de audio

Mono sound

Compresión de audio

G.711(ulaw)/ (AAC-LC)

Velocidad de bits de audio

64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)

Frecuencia de muestreo de audio

8 kHz/16 kHz

Filtro de ruido ambiental

Yes

Red

Seguridad

Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)

Vista en vivo simultánea

Up to 6 channels

Protocolos

TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS, UPnP

Usuario/operador

Up to 32 users

3 user levels: administrator, operator, and user

Cliente

iVMS-4200

*Wi-Fi connection with Hik-Connect directly is not possible

Navegador web

Chrome 57.0+, Firefox 52.0+, Edge 89+

Wi-Fi

Modo de encriptación

WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK

Protocolo de Wi-Fi

IEEE802.11b,IEEE802.11g,IEEE802.11n,IEEE802.11ax

Rango de frecuencia

2.4 GHz to 2.4835 GHz

Canal de ancho de banda

20/40 MHz,Only 802.11n supports 40MHz

Modulación

802.11b: DBPSK, DQPSK, CCK

802.11g: BPSK, QPSK, 16QAM, 64QAM

802.11n: BPSK, QPSK, 16QAM, 64QAM

802.11ax: BPSK, QPSK, 16QAM, 64QAM, 256QAM

Ratio de transferencia

802.11b: up to 11 Mbps

802.11g: up to 54 Mbps

802.11n: up to 150 Mbps

802.11ax: up to 114 Mbps

Alcance inalámbrico

Up to 120 m

(The performance varies based on actual environment)

Antena

1 Antenna

Imagen

Interruptor de parámetros de imagen

Yes

Wide Dynamic Range (WDR)

Digital WDR

SNR

≥ 52 dB

Interruptor día/noche

Day,Night,Auto,Schedule

Mejora de la imagen

BLC,HLC,3D DNR

Configuración de imagen

Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser

Máscara de privacidad

4 programmable polygon privacy masks

Interfaz

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

Micrófono incorporado

1 built-in microphone

Altavoz incorporado

Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB.

Reset Key

Yes

Evento

Evento Básico

Motion detection (support alarm triggering by specified target types (human and vehicle))

Linkage

Notify surveillance center,audible warning

General

alimentación

12 VDC ± 25%, 0.6 A, max. 7.2 W,Ø5.5 mm coaxial power plug,reverse polarity protection,*A switching adapter is included in the package.

Material

Front cover: Plastic, body: Plastic, bracket: Plastic

Dimensión

94.1 mm × 75 mm × 174.5 mm (3.70" × 2.95" × 6.87")

Dimensión del paquete

285 mm × 145 mm × 93 mm (11.22" × 5.71" × 3.66")

Approx. 270 g (0.60 lb.)

Con peso del paquete

Approx. 520 g (1.15 lb.)

Condiciones de almacenaje

-30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)

Condiciones de inicio y funcionamiento

-30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)

Idioma

English, Ukranian

Función general

Heartbeat,mirror,password protection,anti-banding

Certificaciones

RF

CE-RED: EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1 (BT or 2.4G); EN 300328 V2.1.1 (BT or 2.4G); EN 62311:2008 (BT or 2.4G)

EMC

CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021

Seguridad

CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017

Ambiente

CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006

Protección

IP66: IEC 60529-2013
