Descripción

KD8 Series Modular Door StationMain unit of modular door station.2MP fisheye Camera with IR Supplement.One call Physical Button For easier calls.Two-lock control.Standard PoE power supply.IP65 protection level.Convenient configuration via Web remotely.Directly provide 12 V, 500 mA power output for one electronic lock without additional power supply.
System parametersOperation systemLinuxROM32 MBRAM256 MBProcessorEmbeded high performance processorDisplay parametersScreen size/Operation method/Type/Resolution/Video parametersLens2 MP HD cameraResolution2 MPFOVHorizontal: 146°, Vertical: 82°Wide dynamic range (WDR)SupportSupplement lightLow illumination, IR supplement lightsVideo compression standardH.264; H.265; MJPEGAudio parametersAudio input1 built-in omnidirectional microphoneAudio compression standardG.711 U、G.711 A、Opus、AAC-LD、AAC-LC、G.726、G.722.1Audio output1 built-in loudspeakerAudio compression bitrate64 KbpsAudio qualityNoise suppression and echo cancellationVolume adjustmentAdjustableCapacityUser capacity2000Face capacity/Fingerprint capacity/Card capacity6000Message capacity/Linked indoor station capacity500Sub door station capacity16Network parametersNetwork protocolTCP/IP, RTSP, , ipv6, onvifWi-Fi/Bluetooth/3G/4GNADevice interfacesAlarm input4 (2 exit buttons and 2 door contacts by default)Network interface1 RJ-45, 10/100 Mbps self-adaptiveTAMPER1Exit button2 (2 for lock control)RS-4851 (1 for Hikvision's sub module communication)USB/Wiegand/TF card/Alarm output/Lock control2 relays, Max. 30 VDC, 2 ADoor contact input2Two-Wire IP interface/GeneralButton1InstallationSurface mounting, flush mountingIndicator/Net weight: 380 g
Gross weight: 541 g
Protective levelIP65Working temperature-40 °C to 60 °C (-40 °F to 140 °F)Battery/Power supply12 VDC, 500 mA, IEEE 802.3af, PoEApplication environmentOutdoorPower consumption≤ 5 WLanguageEnglish, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese (Taiwan), Latin American Spanish
