Descripción

AX HYBRID PROSistema híbrido: 8 zonas integradas y 56 zonas cableadas/inalámbricas expandibles; 4 salidas integradas (2 salidas NO/NC y 2 salidas PGM) y 60 salidas cableadas/inalámbricas expandiblesComunicación de doble vía de eventos de alarma y otras señales a través de LAN, PSTN, Wi-Fi, GPRS o 3G/4G utilizando un canal principal y de respaldo con prioridad configurableVerificación de video de cámara IP integrada de 4 canales, admite la grabación de video (5 s antes de la alarma + 2 s después de la alarma, o 2 s antes de la alarma + 5 s después de la alarma) para la verificación de la alarma que recibe el correo electrónico o el cliente móvilAdmite armado/desarmado mediante teclado, llavero, cliente móvil, iVMS-4200, SMS y etiquetaEnvía la notificación de alarma a través de mensajes y Hik-ConnectCompatible con protocolos ISAPI, Cloud P2P, ISUP, CSV-IP y DC-09Admite 1 BUS Speed-X
Software featuresZones64 (8 On-board zones, max 8 wired PIRCAM)Particiones32UserInstaller: 1
Administrator: 1
Operator: 62
SMS notificationSupport (with GPRS/3G/4G module)Onboard video clips4ARC protocolISAPI: Supports iVMS-4200 client software and web client
Cloud P2P: Supports cloud P2P privacy protocol
DC-09: ARC accessible（ADM-CID/SIA-DCS ）
CSV-IP: Supports CSV-IP
ISUP: Supports ISUP 5.0
Programming toolsWeb/iVMS-4200/Hik-ProConnect/KeypadFirmware upgradeWeb/iVMS-4200/Hik-ProConnect/Hik-ProConnectEnd of Line ResistanceSupport 1K, 2.2K, 4.7K, 5.6K, 6.8K, 8.2KHardware featuresEntrada de alarma64 (Including 8 on-board zones)Salida de alarma64 (Including 2 on-board relay outputs and 2 on-board I/O outputs)Salida de alimentación1. Bell: maximum 12V 1.2A
2. AUX: maximum 12V 1.5A
3. Bell and AUX maximum 12V 2.1A
3/4G on boardOptionalGPRS on boardOptionalWi-Fi802.11b/g/n (2.4GHz)Bus1 Speed-X busSounder output1 Wired on-board sounder outputTamper-Proof1 switch to detect removal from mounting
1 switch to detect front cover open
Netowrk interface1 RJ45 10M/100M Ethernet interfacepantallaindicador4 On-board LEDs:
① 1 AC power LED indicator (Green)
② 1 System status LED indicator (Green/Red)
③ 1 PSTN status LED indicator (Green/Red)
④ 1 Mobile communication status LED indicator (Green/Red)
Electrical characteristicsInterfaz de energía100 to 240 VAC (on-board power transformer)Consumo de energía1. 220V power supply
① With an alarm: 2A, 32W
② Without an alarm: 250mA, 4W
2. 13.5V battery supply
① With an alarm: 1.7A, 25W
② Without an alarm: 200mA, 2.7W
Battery typeLead acid battery (12V 7Ah, battery is not included by default)Battery life spanUp to 36hrsGeneralOperation temperature-10°C to 40°COperation humidity10% to 90%Shell materialPlasticColorWhiteDimension(WxHxD)261 mm × 199 mm × 86.4 mm997 gDevice managementetiqueta64llavero64Teclado8Wireless sounder16
