6 MP Dual Lens Stitched Wide Angle ColorVu with Smart Hybrid Light Fixed Turret Network Camera

• High quality imaging with 6 MP resolution
• 24/7 colorful imaging
• Support Person and Vehicle Detection
• Smart Hybrid Light: advanced technology with long range cover
• Provide real-time security via built-in two-way audio
• Efficient H.265+ compression technology
• Support on-board storage up to 512 GB (SD card slot)
• Water and dust resistant (IP67)
• 180 Field of view
• Active strobe light and audio alarm to warn intruders off

• Cámara
• Sensor de imagen1/2.5"" Progressive Scan CMOS
• Max. Resolución3632 × 1632
• Iluminación mínimaColor: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light
• Tiempo de obturación1 s to 1/100,000 s
• Día y Noche24/7 color imaging
• Ajuste de ánguloPan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°

• Lente
• LenteFixed focal lens, 2.8 mm
• Focal Length & FOV2.8 mm, horizontal FOV 180°, vertical FOV 79°
• Montura del lenteM12
• Iris TypeFixed
• AperturaF1.0

• DORI
• DORI2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m

• Iluminador
• Tipo de luz suplementariaIR,White Light
• Rango de luz suplementariaUp to 30 m
• Luz de suplemento inteligenteYes
• IR Wavelength850 nm

• Vídeo
• Main stream

  50 Hz: 20 fps (3632 × 1632)

  60 Hz: 20 fps (3632 × 1632)

• Sub-stream

  50 Hz: 20 fps (1200× 536, 960 × 432)

  60 Hz: 20 fps (1200× 536, 960 × 432)

• Compresión de video

  Main stream: H.265+/H.265/H.264+/H.264,

  Sub-stream: H.265/H.264/MJPEG

• Vídeo bitrate32 Kbps to 16 Mbps
• Tipo H.264Baseline Profile,Main Profile,High Profile
• Tipo H.265Main Profile
• Bit Rate ControlCBR,VBR
• Región de interés (ROI)1 fixed region for main stream
• Codificación de video escalable (SVC)H.264 and H.265 encoding

• Audio
• Tipo de audioMono sound
• Compresión de audioG.711/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Velocidad de bits de audio64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
• Frecuencia de muestreo de audio8 kHz/16 kHz
• Filtro de ruido ambientalYes

• Red
• ProtocolosTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP
• Vista en vivo simultáneaUp to 6 channels
• APIONVIF (Profile S, Profile T, Profile G),ISAPI,SDK
• Usuario/operador

  Up to 32 users

  3 user levels: administrator, operator, and user

• SeguridadPassword protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
• ClienteiVMS-4200,Hik-Connect
• Navegador web

  Plug-in required live view: IE 11,

  Local service: Chrome 80+, Firefox 80+, Edge 89+

• Imagen
• Configuración de imagenRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
• Interruptor día/nocheDay,Night,Auto,Schedule
• Wide Dynamic Range (WDR)120 dB
• SNR≥ 52 dB
• Mejora de la imagenBLC,HLC,3D DNR
• Máscara de privacidad4 programmable polygon privacy masks

• Interfaz
• Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
• On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• Micrófono incorporadoYes,1 built-in microphone
• Altavoz incorporadoYes, 1 built-in speaker,Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB.
• Reset KeyYes

• Evento
• Evento BásicoMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
• LinkageUpload to FTP/memory card, send email, notify surveillance center, trigger recording, trigger capture, audible warning, strobe light flashing
